Remote
Power Panel

A Remote Power Panel (RPP) provides local power distribution directly to server racks. These RP Panels are often located at the end of a server rack or on an adjacent wall and are generally used in place of overhead rack busbar to individually feed server cabinets.

Unmatched power distribution

Anord Mardix’s custom engineered RPP delivers unmatched power distribution and boasts the highest level of protection and performance for your critical power systems.  Its highly compact footprint reduces operating costs, increases floor space and allows for the flexible expansion of your power distribution system in the future.

Key features

  • Input connections to suit requirements
  • Top or bottom entry
  • Multiple input capability and traditional
  • Multiple size options – footprint as small as 450mm x 300mm
  • Remote monitoring interface to building management system
  • Welded frame door, door-in-door hinged with dead front
  • Optional seismic rated floor stands available

Enhanced benefits

  • Small footprint provides the flexibility to expand your data centre distribution capabilities and maximises the available floor space
  • Circuit management system provides enhanced power data collection
  • Integrated IR port solutions to identify potential system issues

Specification

DimensionFrom 450mm x 300mm x 2100mm
Construction SeparationForm 2B up to Form 4 Type 6
Number CircuitsUp to 84 SP Circuits
Voltage400v AC
Current RatingUp to 400A
Cable AccessFront
Cable Entry/ ExitTop or Bottom
Ingress ProtectionIP31
